Description
A Low Voltage (LV) Panel is an electrical switchboard used to receive, control, protect, and distribute electrical power at voltages up to 1,000 V AC (typically 415 V, 3-phase in India). It is the backbone of an industrial or commercial electrical distribution system.
Main Functions
* Receives power from a transformer or DG set.
* Distributes power to various loads and sub-panels.
* Protects electrical circuits against overloads, short circuits, and earth faults.
* Monitors electrical parameters such as voltage, current, power, and energy.
* Provides safe isolation for maintenance.
Main Components
* Air Circuit Breaker (ACB) – Main incomer
* Moulded Case Circuit Breaker (MCCB) – Outgoing feeders
* Miniature Circuit Breaker (MCB) – Small circuits
* Busbars (Copper or Aluminium)
* Current Transformers (CTs)
* Multifunction Meter (MFM) / Energy Meter
* Protective Relays
* Selector Switches
* Push Buttons
* Indication Lamps (R-Y-B)
* Surge Protection Device (SPD) (if required)
* Neutral and Earth Busbars
* Terminal Blocks
Types of LV Panels
* PCC (Power Control Center) – Main power distribution
* MCC (Motor Control Center) – Motor control and protection
* APFC (Automatic Power Factor Correction) – Improves power factor
* Distribution Board (DB) – Final power distribution
* Synchronization Panel – Synchronizes multiple DG sets or DG with utility
* PLC Control Panel – Automation and process control
Typical Specifications
* Rated Voltage: 415 V AC, 3 Phase, 4 Wire
* Frequency: 50 Hz
* Current Rating: 63 A to 6300 A
* Short Circuit Rating: 25 kA, 36 kA, 50 kA, or higher (as per design)
* Protection Class: IP42, IP54, IP55, IP65
* Standards: IEC 61439 / IS 61439
Advantages
* Safe and reliable power distribution
* Centralized control and monitoring
* Easy maintenance and troubleshooting
* Modular design for future expansion
* Improved system protection and reliability
Applications
* Manufacturing plants
* Commercial buildings
* Hospitals
* Data centers
* Water treatment plants
* Oil & gas industries
* Shopping malls
* Residential complexes
